Copper Bimetal
O
ur bimetal sheets are used in different industries such as electrical, aerospace and in chemical industries. As one of the leading Bimetal Sheet Suppliers we produce different types of bimetal sheets. There are different combinations such as copper aluminium and gold silver bimetal sheets. These sheets are combination of two different metallic sheets bonded together by rolling process. The Bimetallic Strip Metals are then on each side of the sheet. These could be applied in applications where one side will have different mechanical properties than the other side.
Bimetal Sheet
Bimetallic Wear Plate
Copper Aluminum Bimetal Strips
The Copper Aluminium Bimetal Sheet for example could be used in applications such as electronics, electrical and in metallurgical applications. The Gold Silver Bimetal Sheet is used in the production of jewelries and other appropriate applications. The surfaces of the sheets come with different metals so that the corrosion resistance, wear and tear resistance, electric conductivity and the thermal conductivity of both sides of the sheet differ. This is advantageous in having a Bimetallic Plate so that it can provide with different properties at both surfaces. The making of tubes, containers and other accessories with Bimetallic Sheet provide the accessories with one metal to the outside and another metal to the inside providing different properties that are suitable for the environment they are in touch with Bi Metal Sheet
Specification ,size and dimensions
| Material |
|
|---|---|
| Size |
|
| Thickness |
|
| Standard |
|
| Tensile Strength |
|
| Heat Temperature |
|
| Application |
|
| HS code |
|
| Cu Al Bimetallic plate Type |
|
| Package |
|
| Sheet edges |
|
| Surface finish |
|
| Document provide |
|
| Value added services |
|
| Price term |
|
Copper Aluminium Sheets Technical parameter
| Bimetal Sheets | Base layer thickness(mm) | Cover layer thickness(mm) |
|---|---|---|
| Cu-Al block | Cu δ38~40 | Al δ10~12 |
| Al-Steel block | Steel δ38~40 | Alδ10~12 |
Physical Properties of Aluminium - Copper Bi-metal
| Element | Tensile Strength | Shearing Strength | Heat Temperature | Interface Combination Rate | Interface Full Figure |
|---|---|---|---|---|---|
| Bimetal Sheets | ≥150 Mpa/mm2 | ≥95 Mpa/mm2 | ≦ 400 ℃ | 100% | undulant |
Technical Properties of Bimetal Strip Material
| Property | Aluminum | Copper |
|---|---|---|
| Purity(min) | 99.5% | 99.9% |
| Composition | ||
| By Volume | 80% | 20% |
| By Weight | 55% | 45% |
| Property | Units | COPAL |
| Density at 20º C | Gms/cm³ | 3.95 |
| Max.Electrical Resistivity at 20º C | µ/cm | 2.6 |
| Max.Electrical conductivity at 20º C | % IACS | 65 |
Bimetallic Plate Chart
| Code | Reference | Packing | A (mm) | B (mm) | Tickness (mm) |
|---|---|---|---|---|---|
| PBM1000 | PBM 100x100 | 10 | 100 | 100 | 1,0 |
