Copper Nickel 90/10
Cupronickel 90 / 10 Pipes and Tubes are used for heat exchangers, condensers and piping in seawater systems, marine hardware, and at times for the crankshafts, propellers and hulls of premium fishing boats, tugboats and other working boats. As a supplier, stockiest, exporter and manufacturer, we provide these Cu-Ni 90 / 10 Pipes and Tubes in custom-built thicknesses and sizes according to exact requirements of our well-regarded patrons. We offer the same at economical prices to our consumers.
Cu-Ni 90/10 Pipes & Tubing Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel Cu-Ni 90/10 | 2.0872 | C70600 |
ASTM B 466 Cu-Ni 90/10 Pipes & Tubes Specification
Dimensions : ASTM, ASME and API
Specifications : ASTM / ASME SB 111 / 151 / 466
Grade : Cu-Ni 90/10 (C70600)
Size : 1/2" TO 6' IN OD & NB IN Various SWG & SCH
Outer Diameter: 4.00 to 22.00 mm
Wall Thickness : Between 0.15mm and 1.50 mm
Type : Seamless / ERW / Welded / Fabricated / LSAW Pipes
Form : Round, Rectangular, Hydraulic, Square
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Copper Nickel UNS C70600 Pipes & Tubes Chemical Composition
| Element | Cu - Ni 90/10 |
| Cu | 88.6 min |
| Pb | .05 max |
| Mn | 1.0 max |
| Fe | 1.8 max |
| Zn | 1 max |
| Ni | 9-11 max |
Cupro Nickel 90/10 Pipes & Tubing Physical & Mechanical Properties
| Element | Copper Nickel Cu-Ni 90/10 |
| Density | 8.1 g/cm3 |
| Melting Point | 1443 °C (2430 °F) |
| Tensile Strength | Psi -80,000, MPa -551 |
| Yield Strength (0.2%Offset) | Psi - 35,000, MPa - 241 |
| Elongation | 30 % |
