Stainless Steel Coils
Stainless Steel Shim Supplier, Stainless Steel Shim Manufacturer In India, SS Perforated Shim Stockist, ASTM A240 SS Shim, Stainless Steel Cold Rolled Shims, Stainless Steel Hot Rolled Shims, Stainless Steel Shim 2R (BA) Finish.
Specifications
At Super Company DMCC, we manufacture and export Stainless Steel Pipes 304/316 in different dimensions and shapes that include:
Stainless Steel shim Specification
| Item | Stainless Steel shim(Hot rolled, cold rolled) |
| size | 6 "x50", 6"x100" , 12"x50" ,12"x100" 12"x120", and as per Customer Requirement |
| Thickness | 0.001"to 0.039" and as per Customer Requirement |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 304 shim: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
Stainless Steel shim Application
201 Stainless Steel Coil
| Item | Stainless Steel 201 Coil(Hot rolled, cold rolled) |
| Thickness | 0.025 to 3 mm and as per Customer Requirement |
| Width | 3 mm to 2000 mm and as per Customer Requirement |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 201 Coil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
Stainless Steel 201 Coil Chemical Composition
| Grade |
C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
ASTM A240 SS 201 Coil Mechanical properties
| Properties | Metric | Imperial | |
| Tensile strength (transverse at room temperature) | 685 MPa | 99400 psi | |
| Tensile strength (longitudinal at room temperature) | 696 MPa | 101000 psi | |
| Yield strength (transverse at room temperature) | 292 MPa | 42400 psi | |
| Yield strength (longitudinal at room temperature) | 301 MPa | 43700 psi | |
| Compressive yield strength | 365 MPa | 52900 psi | |
| Elastic modulus | 197 GPa | 28573 ksi | |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 | |
| Elongation at break (longitudinal at room temperature) | 56% | 56% | |
| Elongation at break (transverse at room temperature) | 62.50% | 62.50% | |
| Hardness, Rockwell B (transverse at room temperature) | 85 | 85 | |
| Hardness, Rockwell B (longitudinal at room temperature) | 85 | 85 |
201 Stainless Steel Coil Application
- 201 Stainless Steel Coil Used in Tractor
- 201 Stainless Steel Coil Used in Automotive Trim
- 201 Stainless Steel Coil Used in Stamped Machined Products
- 201 Stainless Steel Coil Used in Cookware
- 201 Stainless Steel Coil Used in Appliances
- 201 Stainless Steel Coil Used in Kitchen
- 201 Stainless Steel Coil Used in Foodservice Equipment
- 201 Stainless Steel Coil Used in Sinks
301 Stainless Steel Coil
Stainless Steel 301 Coil Specification
| Item | Stainless Steel 301 Coil(Hot rolled, cold rolled) |
| Thickness | 0.025 to 3 mm and as per Customer Requirement |
| Width | 3 mm to 2000 mm and as per Customer Requirement |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 301 Coil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
Stainless Steel 301 Coil Chemical Composition
| Element | Percent by Weight/ Type 301 ANN |
| Carbon | 0.150 maximum |
| Manganese | 2.000 maximum |
| Phosphorus | 0.045 maximum |
| Sulfur | 0.030 maximum |
| Silicon | 1.00 maximum |
| Chromium | 16.00 - 18.00 |
| Nickel | 6.000 - 8.000 |
| Nitrogen | 0.10 maximum |
Physical Properties Of Stainless Steel 301 Coil:
| Physical Property | Value |
| Melting Range | 2250-2950°F (1399-1421°C) |
| Density | 0.2850 lb/in3 (7.88g/cm3) |
| Specific Gravity | 8.03 |
| Modulus of Elasticity in Tension | 28•106 psi (193 GPa)* |
| Temperature Range | Mean Coefficient of Thermal Expansion | ||
| °C | °F | cm/cm°C | in/in/°F |
| 20-100 | 68-212 | 16.6·10-6 | 9.2·10-6 |
| 20-300 | 68-572 | 17.6·10-6 | 9.8·10-6 |
| 20-500 | 68-932 | 18.6·10-6 | 10.3·10-6 |
| 20-700 | 68-1292 | 19.5·10-6 | 10.8·10-6 |
| 20-871 | 68-1600 | 19.8·10-6 | 11.0·10-6 |
304 Stainless Steel Coil
Stainless Steel 304 Coil Chemical Composition
- Carban 0.18 to 0.8%
- Crome 18% to 20%
- Nickel 8% to 10%
- Nickel 8% to 10%
Stainless Steel 304 Coil and 304 SS Slitting Coil Specification
| Item | Stainless Steel 304 Coil(Hot rolled, cold rolled), 304 Stainless Steel Slitting Coil |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Grade | ASTM A240, ASME SA240 |
| Thickness | 0.025 to 3 mm and as per Customer Requirement |
| Width | 3 mm to 2000 mm and as per Customer Requirement |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Hardness | Full Hard, Rolled, 1/2 hard or Half Hard, 1/4 Hard or Quarter Hard, 3/4 Hard, Soft or Annealed- Pickled |
| Surface |
Cold rolled (CR), Hot rolled (HR), Galvanized, Plastic Coated, SATIN, 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
Stainless Steel 304l shim Specification
We specialize in the custom manufacturers, suppliers & exporters of 3304L Stainless Steel Shims, 304L SS Shims, UNS S304L00, ASTM A240 Stainless steel 304L Shims and lower-carbon 304L stainless steel shims that offer exceptional mechanical properties and enhanced corrosion resistance. We produce 304 and 304 L stainless steel shims to tight tolerances, and we’re able to meet the demand for custom sizes with industry-leading production capabilities.
Stainless Steel 304l shim Specification
| Item | Stainless Steel 304l shim(Hot rolled, cold rolled) |
| size | 6 "x50", 6"x100" , 12"x50" ,12"x100" 12"x120", and as per Customer Requirement |
| Thickness | 0.001"to 0.039" and as per Customer Requirement |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 304l shim: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Brand: | Indian Origin, European Origin, Japanese Origin, US Origin, Korea Origin, Thailand Origin, Taiwan Origin |
| Manufacturer: | POSCO, Aperam, Jindal Stainless, DKC Korea, Thyssenkrup, Baosteel, TISCO, Arcelor Mittal, VDM, Nippon Metal, Outokumpu |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
Stainless Steel 304l shim Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 304l | 1.4307 | S30403 | SUS 304l | Z3CN18-10 | 304S11 | 03?18?11 | X2CrNi18-9 / X2CrNi19-11 |
Chemical Properties Of 304l Stainless Steel shim:
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
|
304l |
0.03 max |
2.0 |
0.75 max |
0.45 max |
0.03 max |
18.00-20.00 |
- |
8.0-12.0 |
0.10 |
Mechanical Properties Of 304l Stainless Steel shim:
Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
|
304l |
485 |
170 |
40 |
Stainless Steel 310S Shim Physical Properties
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
|
|---|---|---|---|---|---|---|---|
| at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 | |
| 12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | |||||
| 49.6 at 1652 °F | 10.4 at 32 – 1500°F |
