Titanium Products Overview
Titanium is a strong, lightweight metal known for its excellent corrosion resistance, high strength-to-weight ratio, and ability to withstand extreme temperatures. It is widely used in aerospace, medical, and industrial applications due to its unique properties.
Properties of Titanium
- Corrosion Resistance: Titanium is highly resistant to corrosion from most acids, saltwater, and harsh environments.
- High Strength-to-Weight Ratio: Titanium is strong but light, making it ideal for applications requiring strength and reduced weight.
- Non-Toxic: Titanium is biocompatible and is used in medical implants and devices.
- High Melting Point: Titanium has a melting point of 1,668°C, making it suitable for high-temperature applications.
- Non-Magnetic: Titanium is non-magnetic, which makes it ideal for sensitive electronic or medical equipment.
Applications of Titanium Products
- Aerospace Industry: Used in aircraft, spacecraft, and military applications due to its strength and low weight.
- Medical Industry: Used in surgical instruments, implants, and prosthetics due to its biocompatibility and strength.
- Marine Industry: Applied in desalination plants, offshore rigs, and marine equipment because of its corrosion resistance to seawater.
- Automotive Industry: Used in high-performance vehicles, exhaust systems, and engine components to reduce weight and improve performance.
- Chemical Processing: Titanium is widely used in reactors, heat exchangers, and pumps in corrosive environments.
Chemical Composition of Titanium Products
| Product | Ti (%) | Al (%) | V (%) | Fe (%) | O (%) | C (%) |
|---|---|---|---|---|---|---|
| Grade 1 Titanium | 99.5 | 0.2 | 0.1 | 0.2 | 0.18 | 0.08 |
| Grade 5 Titanium | 90-94 | 5.5-6.75 | 3.5-4.5 | 0.25 max | 0.13 max | 0.08 max |
| Grade 2 Titanium | 99.2 | 0.3 | 0.25 | 0.3 | 0.18 | 0.08 |
Mechanical Properties of Titanium Products
| Product | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HRB) |
|---|---|---|---|---|
| Grade 1 Titanium | 240-350 | 140-275 | 24-30 | 50-80 |
| Grade 5 Titanium | 895-1200 | 830-1100 | 10-20 | 35-40 |
| Grade 2 Titanium | 275-450 | 240-350 | 20-25 | 60-90 |
Specification Standards for Titanium Products
| Product | Standard | Description |
|---|---|---|
| Grade 1 Titanium | ASTM B265 | Standard Specification for Titanium and Titanium Alloy Strip, Sheet, and Plate |
| Grade 5 Titanium | ASTM B348 | Standard Specification for Titanium and Titanium Alloy Bars and Billets |
| Grade 2 Titanium | ASTM B338 | Standard Specification for Titanium and Titanium Alloy Seamless Pipe and Tube |
